Description:
AT5000 series spectrum analyzer
will exceed 1Ghz(0.15~1050MHz) have the glancing or fine adjust center
frequency with the 100KHz/grid~100MHz/grid span select, compose the
simple frequency-domain. One 4 and 1/2 bit LED display can be selected
for the center frequency and marking frequency
Features:
§ Frequency range:
0.15~1050MHz
§ 4 and 1/2 digital
displays. (Center frequency, 0.1MHz resolution)
§ -100~+13dBm amplitude
range, 20MHz, 400MHz center frequency span and 4 KHz video filter.
§ Tracking generator (only
the ATTEN5011+)
§ Output amplitude
:+0~-50dBm(50?)
§ Specifications:
§ Frequency range: 0.15
to 1050MHz
§ Center frequency display
accuracy: ±100kHz
§ Marker accuracy: 0.1%
spans 100 kHz
§ Resolution of frequency
display: 100 kHz (4.5 digit LED)
§ Frequency scans width
accuracy: ±10%
§ Frequency stability:
better than 150 kHz/ hour
§ IF Bandwidth (-3dB): 400
kHz and 20 kHz;
§ Video-Filter (ON): 4 kHz
§ Sweep rate: 43Hz
§ Amplitude range: -100dBm
to +13dBm
§ Screen display range:
80dB (10dB/div.)
§ Reference level: -27dBm
to +13dBm (in 10dB steps)
§ Reference level
accuracy: ±2dB
§ Average noise level:
-90dBm (20 kHz Bandwidth)
§ Distortion: < -55dBc
of 2nd and 3rd harmonic
§ Third order intermod.:
-70dBc (two signals > 3MHz apart)
§ Sensitivity: Better than
-90dBm
§ Log scale fidelity: ±2dB
(without attn.) 500MHz
§ Input attenuator: 0 to
40dB (4×10dB steps)
§ Input attenuator
accuracy: ±1dB/10dB
§ Max. Input level:
+10dBm, ±25V DC (0dB attn.) +20dBm (40dB attn.)
§ Frequency scans width:
100 kHz/div. to 100MHz/div, in 1-2-5
steps and 0Hz/div. (Zero Scan)
